Colorlight 3D LED Display controller 3D Sender Overview
3D sender is specially designed for ordinary LED display to achieves 3D effect. With the transmitter, and shutter type 3D glasses together, 3D Sender can make
the ordinary LED display play as a 3D display, and it can be easily switched between 2D and 3D mode.
It has the strongest receiving capability of 4K, can receive signal with 4096*2160 pixels in maximum. এটা আছে 4 gigabit Ethernet outputs to support supper large screen.
Its LCD can show the real-time information about screen status and the control panel supports quick setting of LED display without need of computer.
Colorlight 3D LED Display controller 3D Sender Features.
Support 3D display
ইনপুট রেজোলিউশন: The maximum resolution is 4096*2160 পিক্সেল,
সর্বোচ্চ লোড ক্ষমতা:2621440pixels @4096*2160 pixels (2D Mode);
1310720pixels @2048*2160 pixels (3D Mode);
Quick setting of screen without computer by use of control panel
LCD shows real-time information of screen status
Support one key to lock and one key to black screen
Support HDMI and DVI signal input
One key switching from DVI to HDMI
Support external audio input
Support high level video input: 12bit/10bit/8bit
4 gigabit Ethernet outputs support screen arbitrary splicing
উচ্চ গতির কনফিগারেশন এবং সহজ ক্যাসকেডিংয়ের জন্য ডুয়াল USB2.0
Support systematic time encryption
Internal testing program, support offline testing
Brightness adjustment in 256 levels by knobs
Preset startup picture of display
Compatible with all receiver series, like 5A, i5A
| Video source interfaces | |
| Interface type | DVI*1，HDMI*1 |
| ইনপুট রেজোলিউশন | 4096*2160pixels in maximum |
| Auto-adjust resolution | সমর্থন |
| Video source frame rate | 60এইচজেড，support auto-adjustment |
| ইনপুট রঙ | 12/10/8বিট |
| আউটপুট | |
| Net port number | 4 gigabit net ports |
| Control area by port | 2ডি মোড: 2621440 , each port: 655430পিক্সেল; |
| 3ডি মোড 27680 , each port: 1310720পিক্সেল; | |
| সংক্রমণ দূরত্ব | CAT5E??40এম；CAT6 70M；NO limitation on optical fiber |
| ক্যাসকেডিং | Support arbitrary cascading between net ports |
| Transmission mode | ফ্রেম মোড, CRC check in addition |
| Connected equipment | |
| Receiver card | 5A series, i5A series, customization cards, ইত্যাদি. |
| পেরিফেরাল | মাল্টিফাংশন কার্ড, optical fiber transceiver, gigabit switcher |
| স্পেসিফিকেশন | |
| আকার | 1ইউ স্ট্যান্ডার্ড বক্স |
| ইনপুট ভোল্টেজ | এসি 100 ~ 240 ভি |
| রেট পাওয়ার | 10ডব্লিউ |
| খরচ | |
| ওজন | 2কেজি |
| বাহ্যিক ইন্টারফেস | |
| এলসিডি | Show real-time information of screen, help to make quick setting |
| of screen | |
| Control panel | Rich bottom for quick setting the screen |
| Configuration interface | ইউএসবি 2.0*2 |
| DVI information | ফ্রেম রেট সম্পর্কে বর্তমান তথ্য, খালি মান, ঘড়ি, judge status |
| between video card and video processor; | |
| Brightness control | Adjustment in 100 স্তর, automatically save in sending card. |
| Bottom | |
| Real-time configuration | গামা, নিয়ন্ত্রণ এলাকা, পরামিতি সেটিং |
| Smart detection system | Support temperature, আর্দ্রতা , ইত্যাদি. |
| Real-time clock | Internal real-time clock, backup battery, total running time can be |
| calculated, preset working status in order | |
| না. | ইন্টারফেস | ফাংশন | Noted |
| 1 | পাওয়ার সুইচ | power on /off | |
| 2 | number keypad | 0-9, for the numerical input | |
|
3 |
এলসিডি |
To show information, such as logo,
running state, ইত্যাদি. |
|
|
4 |
Function keys |
Extended function, such as Menu
‘black’，‘Fn??function combination key)，‘DVI/HDMI??/টিডি> |
|
|
5 |
Spin bottom |
Used for brightness adjustment
and assisted selection |
|
|
6 |
পাওয়ার সাপ্লাই |
AC power supply interface
(AC100-240V) |
|
| 7 | 3D sync interface | 3D ইমিটারের সাথে সংযোগ করুন | |
|
8 |
অডিও ইনপুট |
transmit the audio signal to the
মাল্টি-ফাংশন কার্ড |
|
| 9 | DVI ইনপুট | DVI signal input | |
| 10 | HDMI ইনপুট | HDMI সংকেত ইনপুট | |
|
11 |
ইউএসবি 2.0 |
For iQ7E and PC communication or
iQ7E cascade |
|
|
12 |
আউটপুট পোর্ট |
RJ45,4 outputs, connect to receiver
cards |
